Plastic Security Seals – Type 1 (Reinforced Metal Closure)

Reinforced plastic seal type 1 drawing

Plastic Security Seals – Type 1 (Reinforced Metal Closure)

1,00

Reinforced plastic seal type 1 drawing
Other versions available :
Type 2 : adjustable closure plastic seal
Type 3 : high resistance plastic seal
Type 4 : steel seal

Practical inviolable seal, progressively numbered. The closure is reinforced with a metal insert for maximum security. Its slim body makes it very versatile and applicable from minimum holes of just 2.5 mm. Non-reusable, it is ideal for sealing packaging with sensitive contents, for identifying and recognizing any object such as trolley, fire extinguishers, security doors, clothing, safety boxes, emergency kits etc. It is suitable for multiple uses also in the transport sector. Other colors or customizations available on request.

SKU: N/A Category:
Code Description Size (mm) Box Qty Plate size (mm) Colour
8804 SEAL TYPE 1 385 x 2,3 1000 22X40 BLUE
8814 SEAL TYPE 1 285 x 2,3 1000 22X40 BLUE
Code Description Size (mm) Box Qty Plate size (mm) Colour
8802 SEAL TYPE 1 385 x 2,3 1000 22X40 YELLOW
8812 SEAL TYPE 1 285 x 2,3 1000 22X40 YELLOW
Code Description Size (mm) Box Qty Plate size (mm) Colour
8803 SEAL TYPE 1 385 x 2,3 1000 22X40 RED
8813 SEAL TYPE 1 285 x 2,3 1000 22X40 RED
Code Description Size (mm) Box Qty Plate size (mm) Colour
8805 SEAL TYPE 1 385 x 2,3 1000 22X40 GREEN
8815 SEAL TYPE 1 285 x 2,3 1000 22X40 GREEN
Code Description Size (mm) Box Qty Plate size (mm) Colour
880E SEAL TYPE 1 385 x 2,3 1000 22X40 WHITE
881E SEAL TYPE 1 285 x 2,3 1000 22X40 WHITE
Code Description Size (mm) Box Qty Plate size (mm) Colour
8807 SEAL TYPE 1 385 x 2,3 1000 22X40 ORANGE
8817 SEAL TYPE 1 285 x 2,3 1000 22X40 ORANGE

Cobra® Plastic Security Seals Type 1 - Adjustable, Metal-Reinforced Closure

Cobra® Type 1 security seals are adjustable plastic seals with a metal-insert locking mechanism, providing a tamper-evident closure for containers, valves, meters, and equipment. Once locked, the seal cannot be opened without visible destruction, providing clear evidence of unauthorised access.
Available in assorted colours for colour-coded identification. Adjustable length.
B2B supply to logistics operators, utilities, industrial plant managers, and security equipment distributors across Europe.
The target plate can be customized with printed numbers, letters and barcodes according to customer requirements. Subject to individual evaluation.

Plastic Security Seals Type 1 — Metal-Insert Tamper-Evident Seals

Cobra® Type 1 plastic seals are single-use tamper-evident fasteners for securing containers, gates, valves, electric meters, fire extinguishers, and access panels. The metal insert inside the locking head provides resistance to manipulation.

Seal Types Comparison

Type 1 (this product) - Metal-reinforced closure:
Highest pull-out resistance in the Cobra® seal range. Specified for utility meters, fuel valves, high-security containers, and applications where a greater deterrence to tampering is required.
Type 2 - Adjustable plastic closure:
Good pull-out resistance and adjustable closure adjustable closure thanks to the ratchet mechanism (notches) . General logistics, industrial, and administrative sealing.
Type 3 - High-resistance construction:
Heavy-duty seal for applications requiring higher break force. The seal body is the widest among these models, ensuring a tight seal.

Technical Specifications

Material Plastic body with metal-insert locking mechanism
High quality food grade polypropylene + Galvanized Steel Closing Spring
Also known as Security seals, tamper-evident seals, container seals, meter seals
Closure type metal-reinforced lock
Tamper evidence Seal cannot be removed without visible destruction
Single-use Yes — non-releasable after locking, final closure
Colours Assorted (multiple colours for colour-coded identification)
Compliance CE European Norms

Applications

  • Utility metering: electricity, gas, and water meter sealing
  • Logistics and supply chain: container, trailer, and pallet seal
  • Industrial plant: valve and sampling point tamper-evidence
  • Fire safety equipment: extinguisher pin and inspection sealing
  • Pharmaceutical and food: tamper-evident packaging and storage sealing
