| Code | Description | Size (mm) | Max. bundle Ø (mm) | Guaranteed min. tensile strenght (kg) | Box Qty | Colour |
|---|---|---|---|---|---|---|
| 9600 | CABLE TIE WITH MARKER TYPE 1 | 100 x 2,5 | 15 | 8,1 | 5.000 | NATURAL |
| 9610 | CABLE TIE WITH MARKER TYPE 1 | 200 x 2,5 | 53 | 8,1 | 5.000 | NATURAL |
Cable Ties with Marker Plate, Type 1 (Under-Head)
Cable Ties with Marker Plate, Type 1 (Under-Head)
1,00€
Other versions available: Cable ties with UP head marker plate, type 2 Cable ties with UNDER head marker plate, type 3 big
Wiring cable ties made of nylon PA6.6, natural color, are suggested for the fixing and identification of small bundle of cables. The hooking system between the pawl and the rack permits the fixing of various diameters. The marker plate, (25,4×8) mm, is part of the body of the tie,perpendicular to what is being fixed. Its surface can be written with a marker pen.
Cobra® Cable Ties with Marker Plate Type 1 - Under-Head Identification Tag, PA6.6, Made in Italy
Cobra® Type 1 identification cable ties feature an integrated writeable marker plate positioned under the head, flush with the cable bundle. The 25.4 × 8 mm tag surface is compatible with permanent markers and printed labels, enabling direct cable identification without additional components.
Available in PA6.6 natural. Operating temperature: −40°C to +85°C. CE compliant.
B2B supply to electrical contractors, panel builders, network installers, and OEM manufacturers across Europe and worldwide.
Identification Cable Ties with Under-Head Marker Plate - Type 1
Cobra® Type 1 marker plate cable ties integrate the identification tag and the fastening function into a single component. The tag is moulded under the head, meaning it lies flat against the cable bundle when tightened and does not project outwards, making it suitable for installations with limited clearance.
The target plate can be customized with printed numbers, letters and barcodes according to customer requirements. Subject to individual evaluation.
Marker Plate Position and Design
The Type 1 marker plate is located on the underside of the head, against the cable bundle surface when installed. Tag dimensions: 25.4 × 8 mm. The writing surface is smooth, compatible with permanent markers and self-adhesive printed labels. The tag is integral to the cable ties.
Choosing the Right Identification Cable Tie: Type 1 vs. Type 2 vs. Type 3
Marker cable ties under-head, Type 1:
Tag faces the bundle. Suitable for installations where the identification must be visible from a specific viewing angle or where projecting tags would obstruct adjacent components. Use where lateral clearance is limited. Tag dimensions: 25.4 × 8 mm.
Marker cable ties above-head, Type 2 :
Tag faces away from the bundle, towards the viewer. Best readability in open installations, cable trays, and racks where the tie head is visible from above or the front. Tag dimensions: 20.4 × 9 mm.
Marker cable under-head and larger tag, Type 3 :
Larger tag area for more text, barcodes, or QR codes. Same under-head position as Type 1.
Tag dimensions: 13 × 28 mm.
Technical Specifications
| Material | Polyamide 6.6 (PA6.6) — first-class |
| Also known as | Identification cable ties, label cable ties, marker cable ties |
| Tag position | Under-head (against bundle surface when installed) |
| Tag dimensions | 25.4 × 8 mm |
| Colour | Natural |
| Operating temperature | −40°C to +85°C |
| Assembly temperature | −10°C to +60°C |
| Compliance | CE European Norms |
| Brand | Cobra® by Cieffeplast |
| Country of origin | Italy |
Applications
- Electrical panel wiring: circuit and feeder identification
- Control cabinet cabling: PLC and fieldbus cable labelling
- Data centre structured cabling: patch cord and trunk cable identification
- Wiring harness assembly: wire and loom identification in OEM production
- Building services: pipe and cable identification in HVAC and BMS installations
